Installation, Programming and Maintenance Microdos Pooltec
Rev. 1.0 EN
39
4.5.3.7. mA OUTPUT (OPTIONAL)
It is possible (OPTIONAL) to add up to 2 milliamperes (mA) outputs to connect the Microdos Pooltec to regulation pumps that are
controlled by 0/4 – 20mA standard:
By pressing the EXPERT button, this window will appear:
TO MODIFY THE PARAMETERS VALUE:
• Press on the button of the value you wish to modify and use the ▲ ▼ arrows.
•
Press SAVE to make the modification effective.
Select the initial scale value 0mA or
4mA.
Select the measure that you want
to connect to the mA output.
Select by ▲ ▼ arrows the value of the measure
that correspond to the initial scale (0/4mA).
Select by ▲ ▼ arrows the value of the measure
that corresponds to the end scale 20mA.
Restores mA parameters to factory values.
Access Expert menu (complex settings).
EXPERT PASSWORD required.
Turn off the Overdose alarm
and restores the mA output.
Value of mA output when there is an
alarm (standby, general flow, pump
OVERDOSE: maximum dosing time
alarm. When the set time is reached,
the mA output goes to AL.mA value
(stop dosing).
Value "00:00"
→
no programming
Press HIDE to go back to the basic menu.
