microSYST migra Ethernet/IP User Manual

migra Ethernet/IP
Large Format, Graphics Compatible Display with Ethernet/IP Interface
Page 12
microSYST Systemelectronic GmbH, Am Gewerbepark 11, 92670 Windischeschenbach
 +49 9681 91960-0,  +49 9681 91960-10, info@microsyst.de, www.microsyst.de
3.6 Configuration of the migra with software “micon”
The enclosed software “micon 5” serves for the configuration of the display’s
variables and graphics.
 Connect a PC / Laptop via Ethernet with the display (1 : 1 cable if using a
switch/hub; crosslink cable at direct connection).
Installation
 Execute the enclosed file “setup.exe” in the path “MICON” of the enclosed
CD and follow the instructions.
Start
After the start, the dialog “Properties” appears.
The IP address of the display must be specified by the user.
Interface must be set to
“HMS-Interface (64kb
Flash)“.
