3.10.6 Macros
Macros are predefined command sequences included in the device
configuration.
They are analogous to the data units in the online frames.
The first macro is executed after the device is switched on (if one
exists). Subsequent macros are executed every 100 ms. Macro
execution is stopped after the last macro has been executed.
3.10.6.1 Start Macro Execution
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
ESC
Function
Macro no.
hundreds
Macro no.
tens
Macro no.
ones
1B
h
“M”
“0” – “9”
“0” – “9”
“0” – “9”
Execution starts with the indicated macro.
Skipping is also possible during macro execution through the use of this
command within a macro sequence.
