3.10.2.8 Querying Bar Graphs
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
ESC
Function
Display / Clear
Bar graph no.
hundreds
Bar graph no.
tens
Bar graph no.
ones
1B
h
“W”
“+”: display
“-”: clear
“0” – “9”
“0” – “9”
“0” – “9”
When a bar graph is displayed, the last bar graph value transmitted to
the display is used (or the reference value after a reset). If a variable is
linked to the bar graph, it is also displayed accordingly.
When the display is cleared, the surface at which the bar graph is
displayed is overwritten with the current online background colour (from
the last “ESC-A” frame)! Black is used if the background colour has
been set to transparent! If a variable is linked to the bar graph, it is
cleared from the display as well.
Up to 255 bar graphs are possible (numbers 0 through 254).
The maximum variable length for linked variables is 127 characters.
3.10.2.9 Setting Bar Graph Values
3.10.2.9.1 ASCII Coded Decimal Values
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
ESC
Function
Set
Bar graph no.
hundreds
Bar graph no.
tens
Bar graph no.
ones
Type of
transmitted
data
1B
h
“W”
“=”: set
“0” – “9”
“0” – “9”
“0” – “9”
“A”: ASCII
coded
decimal value
Byte 8
Byte 9
Byte 10
Byte 11
Byte 12
Byte 13
Plus or minus
sign
Decimal value
ten thousands
Decimal value
thousands
Decimal value
hundreds
Decimal value
tens
Decimal value
ones
“+”, “-“
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
