microSYST migra Ethernet/IP User Manual

migra Ethernet/IP
Large Format, Graphics Compatible Display with Ethernet/IP Interface
Page 37
microSYST Systemelectronic GmbH, Am Gewerbepark 11, 92670 Windischeschenbach
 +49 9681 91960-0,  +49 9681 91960-10, info@microsyst.de, www.microsyst.de
3.10.6.3 Pause during Macro Execution
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
ESC
Function
Pause duration
hundreds
Pause duration
tens
Pause duration
ones
1B
h
“w”
“0” – “9”
“0” – “9”
“0” – “9”
Sets the time which elapses until the next macro is executed (in steps of
100 ms).
A macro is normally executed every 100 ms until the last macro has
been completed.
After the ESC + “w...” sequence, macro execution is stopped for the
specified pause duration.
This sequence can be used as part of a macro, as well as part of a
receive frame.
3.10.6.4 Stop Macro Execution
Byte 1
Byte 2
ESC
Function
1B
h
“E”
