3 Technical Data
General Specifications
Display type: LED dot matrix display
Display: ASCII characters (Windows character set), graphics
Display colour: type SC: single colour, type MC: multicolour
View: single or double sided
Operating voltage: 230 V / 50 Hz, 110 V / 60 Hz or 24 VDC +/-20 %
Protocol: Ethernet/IP
Connection: RJ45, 10/100 MBit/s,
configuration via RS232 interface
Housing: powder coated aluminium
Housing dimensions: see chapter “device configuration”
Mounting: articulated arm or hanging mount
bracket for wall mounting
Protection: IP 54 or IP 65
Operating temperature: 0 to +50 C (optionally –20 to +50 °C)
Storage temperature: -25 to +70 C
Graphics: max. 1000
Texts: max. 1000 (max. 255 moving screen texts)
Variables: max. 1000
Macros: max. 1000
Character sets: max. 100
The available flash memory capacity for graphics, texts, variables,
character sets and macros depends on the vertical resolution of the
display:
 Vertical resolution ≤ 64 Pixel: 64 KByte
 Vertical resolution > 64 Pixel: 448 KByte
