3.10.2.6 Increasing and Decreasing Variables
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
ESC
Function
Increase /
Decrease
Variable no.
hundreds
Variable no.
tens
Variable no.
ones
1B
h
„V“
“I”: increase
or
“D”: decrease
“0” – “9”
“0” – “9”
“0” – “9”
Only numeric characters are changed. Letters, commas etc. are
skipped. Numeric characters are interpreted as an single decimal
number. This decimal number is increased or decreased by 1.
In order to avoid flickering, the old display is not cleared until after the
new display is read out!
The background colour used with the variables may not be transparent,
and a character set with uniform character width should be used in order
to assure correct display. Otherwise, the variable must be cleared prior
to changing, and then displayed once again!
Variable content is stored to RAM only. After the device has been
switched off and back on again, the variables are returned to their pre-
configured values.
3.10.2.7 Positioning Variables
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5.
Byte 6
ESC
Function
Set
Variable no.
hundreds
Variable no.
tens
Variable no.
ones
1B
h
“V”
“P”: set position
“0” – “9”
“0” – “9”
“0” – “9”
Byte 7
Byte 8
Byte 9
Byte 10
Byte 11
Byte 12
X position
hundreds
X position
tens
X position
ones
Y position
hundreds
Y position
tens
Y position
ones
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
Variable positioning is stored to RAM only. After the device has been
switched off and back on again, the variables are returned to their pre-
configured positions.
