microSYST migra Ethernet/IP User Manual

migra Ethernet/IP
Large Format, Graphics Compatible Display with Ethernet/IP Interface
Page 40
microSYST Systemelectronic GmbH, Am Gewerbepark 11, 92670 Windischeschenbach
 +49 9681 91960-0,  +49 9681 91960-10, info@microsyst.de, www.microsyst.de
3.13 Examples
Read out online text to the large format display unit at address 1:
1. Without checksum, with response
STX
DA
SA
FC
Data-Unit
ETX
Start of text
Display unit
address
Source
address
Frame control
“Hello world”
End of text
00000010
B
10000001
B
10000000
B
10000001
B
00000011
B
2
129
128
129
...
3
Response from large format display unit if no errors occur:
STX
DA
SA
FC
Data-Unit
ETX
Start of text
Destination
address
Source
address
Frame control
Error code
End of text
00000010
B
10000000
B
10000001
B
10000000
B
00000011
B
2
128
129
128
„0“
3
2. With checksum and response (in short form)
The character “A” is to be displayed at the large format display unit at
address 1:
Master : 02 81 80 83 F0 F1 41 FA F6 03
Display unit: 02 80 81 80 30 03
The frame to be transmitted including TB and LB:
Master : 01 0A 02 81 80 83 F0 F1 41 FA F6 03
Response from the display including TB and LB:
Display unit: 02 06 02 80 81 80 30 03
