3.10.5 Digital Inputs and Outputs
Large format display with a vertical resolution of up to 64 pixels can
optionally be equipped with up to 16 digital inputs and 16 digital outputs.
Large format display with a vertical resolution of more than 64 pixels can
optionally be equipped with up to 16 digital inputs.
Request Frame
Byte 1
Byte 2
Byte 3
Byte 2+n
Byte 18
ESC
Function
Output bit 1
Output bit n
Output bit 16
1B
h
“D”
“0” or “1”
“0” or “1”
“0” or “1”
“0” -> clear output
“1” -> set output
else -> retain previous output status
Response: (FC byte, bit 0 = 1)
Byte 1
Byte 2
Byte 3
Byte 2+n
Byte 18
ESC
Function
Input bit 1
Input bit n
Input bit 16
1B
h
“D”
“0” or “1”
“0” or “1”
“0” or “1”
“0” -> input cleared
“1” -> input set
The output bits are used to switch the digital outputs (if included).
After switching the device on, all outputs are cleared (0).
