3.10.1.2 Positioning the Cursor
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
ESC
Function
X Position
hundreds
X Position
tens
X Position
ones
Y Position
hundreds
Y Position
tens
Y Position
ones
1B
h
“C”
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
“0” – “9”
3.10.1.3 Configuring Attributes
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
ESC
Function
Foreground colour
Background colour
Blinking
1B
h
“A”
“0”: black
“1”: green
“2”: red
“3”: yellow
“0”: black
“1”: green
“2”: red
“3”: yellow
“T”: transparent
“0”: static
“1”: blinking
