3.10.2 Texts, Graphics and Variables
3.10.2.1 Querying Text
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
ESC
Function
Display / Clear
Text no.
hundreds
Text no.
tens
Text no.
ones
1B
h
“T”
“+”: display
“-”: clear
“0” – “9”
“0” – “9”
“0” – “9”
When the display is cleared, the surface at which the text is displayed is
overwritten with the current online background colour (from the last
“ESC-A” frame)! Black is used if the background colour has been set to
transparent!
3.10.2.2 Adjusting Speed for Moving Screen Texts
Byte 1
Byte 2
Byte 3
ESC
Function
Moving Screen Speed
1B
h
“L”
“0”: static
“1”: 1.8 seconds
:
“9”: 0.2 seconds
All moving screen texts are set into motion at the selected speed. The
default setting is “9” (0.2 seconds per step), and this setting is always
activated each time the device is switched on.
3.10.2.3 Querying Graphics
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
ESC
Function
Display / Clear
Graphic no.
hundreds
Graphic no.
tens
Graphic no.
ones
1B
h
“G”
“+”: display
“-”: clear
“0” – “9”
“0” – “9”
“0” – “9”
When the display is cleared, the surface at which the text is displayed is
overwritten with the current online background colour (from the last
“ESC-A” frame)! Black is used if the background colour has been set to
transparent!
