3.10.4 General Functions
3.10.4.1 Selecting Blinking Period Duration
Byte 1
Byte 2
Byte 3
ESC
Function
Blinking period duration
1B
h
“B”
“0”: 2 seconds
:
“9”: 0.2 seconds
The selected blinking period duration applies to all blinking texts.
The default value (“9”) is activated each time the device is switched on.
3.10.4.2 Adjusting Brightness
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
ESC
Function
Colour
Brightness
hundreds
Brightness
tens
Brightness
ones
1B
h
“H”
“1” – “2”
“0” – “9”
“0” – “9”
“0” – “9”
Within a range of 0 to 100% for each of the following colours:
“1” = green
“2” = red
The transmitted value is multiplied in accordance with the HEX switch
settings at the device before it is applied.
