3.11 Response Frames
A response frame is only transmitted if the corresponding bit (bit 0) has
been set in the FC byte, and if the broadcast address (127) has not
been used as the destination address.
Example: display unit address = 1
master address = 0
Response frame from the display unit to the master:
STX
DA
SA
FC
Data-Unit
ETX
Start of text
Destination
address
Source
address
Frame
control
Error code
End of text
00000010
B
10000000
B
10000001
B
10000000
B
00000011
B
2
128
129
128
“0” – “5”
3
Error Codes and their Meanings:
Value
(ASCII character)
Meaning
“0”
No error
“1”
Incorrect checksum
“2”
Reserved
“3”
Incorrect number of data bytes (LEN-H/L),
invalid escape sequence
“4”
Element (text, variable, graphic, character set
or macro) is missing, invalid parameter
“5”
Invalid flash
The queried information is returned instead of error code “0” for frames
which require a response (“reading out decimal point from the display”,
“digital inputs and outputs”).
The error code in the response frame always relates to the last partition
frame.
