microSYST migra Ethernet/IP User Manual

migra Ethernet/IP
Large Format, Graphics Compatible Display with Ethernet/IP Interface
Page 28
microSYST Systemelectronic GmbH, Am Gewerbepark 11, 92670 Windischeschenbach
 +49 9681 91960-0,  +49 9681 91960-10, info@microsyst.de, www.microsyst.de
3.10.3 Direct Graphic Control
3.10.3.1 Clear Display and Fill
Byte 1
Byte 2
Byte 3
ESC
Function
Colour
1B
h
“F”
“0”: black
“1”: green
“2”: red
“3”: yellow
3.10.3.2 Setting the Decimal Point
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Byte 9
ESC
Function
Colour
X pos.
hundreds
X pos.
tens
X pos.
ones
Y pos.
hundreds
Y pos.
tens
Y pos.
ones
1B
h
“P”
“0”: black
“1”: green
“2”: red
“3”: yellow
“0” - “9”
“0” - “9”
“0” - “9”
“0” - “9”
“0” - “9”
“0” - “9”
3.10.3.3 Reading Out the Decimal Point from the Display
Query:
Byte 1
Byte 2
Byte 3
Byte 4
Byte 5
Byte 6
Byte 7
Byte 8
Byte 9
ESC
Function
Query
code
X pos.
hundreds
X pos.
tens
X pos.
ones
Y pos.
hundreds
Y pos.
tens
Y pos.
ones
1B
h
“P”
“?”
“0” - “9”
“0” - “9”
“0” - “9”
“0” - “9”
“0” - “9”
“0” - “9”
Response:
Colour Information (with header and trail)
Byte 1
Byte 2
Byte 3
ESC
Function
Colour
1B
h
“P”
“0”: black
“1”: green
“2”: red
“3”: yellow
