migra Ethernet/IP
Large Format, Graphics Compatible Display with Ethernet/IP Interface
Page 27
microSYST Systemelectronic GmbH, Am Gewerbepark 11, 92670 Windischeschenbach
+49 9681 91960-0, +49 9681 91960-10, info@microsyst.de, www.microsyst.de
If a variable is linked to the bar graph, it is changed accordingly as well:
All digits occupied with the characters “#” and “*” are overwritten with the
new value starting at the right.
If a variable is preset to “#”, preceding zeros are suppressed (i.e.
replaced with blanks).
If a variable is preset to “*”, preceding zeros are displayed.
If a digit is occupied by the dollar sign ($), it is overwritten with the new
preceding plus or minus sign.
Example: Variable preset = “$ #*,* m/s”
Value = -9 = “-00009”
=> Display = “- 0,9 m/s”
If minimum or maximum values are violated, the current values blinks at
the display.
The background colour used for variables may not be transparent, and a
character set with uniform character width should be used in order to
assure correct display.
