microSYST migra Ethernet/IP User Manual

migra Ethernet/IP
Large Format, Graphics Compatible Display with Ethernet/IP Interface
Page 36
microSYST Systemelectronic GmbH, Am Gewerbepark 11, 92670 Windischeschenbach
 +49 9681 91960-0,  +49 9681 91960-10, info@microsyst.de, www.microsyst.de
Example:
Macro no.
Macro command
1
000
ESC-M005E0=1
2
001
ESC-M007E1#1
3
002
ESC-M009E2=1
4
003
ESC-w010
5
004
ESC-M000
6
005
ESC-T+000
7
006
ESC-M000
8
007
ESC-T+001
9
008
ESC-M000
10
009
ESC-F0
11
010
ESC-M000
 The Inputs 0 to 2 are queryied every 1 second.
 If Input 0 is set, text „000“ is displayed.
 If Input 1 is set, text „001“ is displayed.
This also happens, if the input was set only for a short time (at least
100 ms), for example during the delay time (1 second).
 If Input 2 is set, the display is cleared.
