Guidelines for Loading - continued
M11 (maximum capacities)
Load Type M11 Large Tray M11 Small Tray M11 Sterilizer Total
SolidItems 45 instruments -
2.7lbs.,(1225grams)or
30 instruments -
1.8lbs.,(816grams)or
150 instruments -
9.0lbs.,(4082grams)or
Handpieces 9 in a rack or 9 in a rack or 9 handpieces in a rack and
75 instruments or
Packs*
270 in
3
(< 2 in. thick)
4425 cm
3
(< 5 cm thick)
195 in
3
(< 2 in. thick)
3195 cm
3
(< 5 cm thick)
930 in
3
(< 2 in. thick)
15240 cm
3
(< 5 cm thick)
*Allow a minimum of 1/4” (6.4 mm) space between each pack, and also from the chamber wall.
Load Size
Refertothechartsbelowformaximumsterilizationloads.Ifaloadsurpassestheselimits,werecommend
dividingtheloadandrunningmultiplecycles.Listedbelowarethemaximumrecommendedloadsfor
each tray and total loads:
WARNING
Do not overload the chamber. Adequate space is required around items in trays
for steam circulation and drying. Failure to allow adequate space will compromise
sterilization and drying. Do not run the sterilizer without the tray plate in place.
M9 (maximum capacities)
Load Type M9 Large Tray M9 Small Tray M9 Sterilizer Total
SolidItems 42 instruments -
2.4 lbs. (1089 grams) or
28 instruments -
1.6 lbs. (726 grams) or
140 instruments -
8.0 lbs. (3629 grams) or
Handpieces 9 in a rack or 9 in a rack or 9 handpieces in a rack and
75 instruments or
Packs*
66 in
3
(< 1 in. thick)
1082 cm
3
(< 2.5 cm thick)
48 in
3
(< 1 in. thick)
787 cm
3
(< 2.5 cm thick)
228 in
3
(< 1 in. thick)
3736 cm
3
(< 2.5 cm thick)
