VetPro DC Installation/Service Manual, 00-02-1606, Revision R01
109
Horizontal
Arm Brake
Assembly
Locate the friction assembly screws. Using a 3 mm hex key, as shown in Figure
105, tighten or loosen screws as necessary to get proper movement without
unwanted horizontal movement of the Articulating Arm.
Do not attempt to adjust any other screws in the horizontal
arm.
Figure 105
Adjusting the
Articulating Arm
Brake Assembly
