Technical Information
56
T 80xx
no longer detected.
Remedy:
1. Dry the reed switch plug with a hot-air dryer or hair dryer.
2. Re-insert the plug.
3. Check whether “Condenser” is now detected.
4. If “Condenser” is not detected, replace the reed switch.
5. Check the dryer for leaks in the area of the condensate pump and repair
as necessary.
Cause:
Faulty/missing non-return valve. If the dryer drains off condensation
externally and the siphon is also connected to a washing machine or wash
basin, then drain water can flow back into the dryer.
Remedy:
Install/replace a non-return valve.
4 Service
4.1 Programming Mode Summary
Initial requirements:
1. End the current program as well as the demo mode.
2. Switch the dryer off.
3. Close the door.
Accessing:
Note: Access has to be completed within 10 seconds.
1. Press and hold the Start/Stop button.
2. Switch the dryer on.
3. As soon as the “Start/Stop” LED flashes, release the Start/Stop button.
4. Immediately press Start/Stop 5 times and on the 5th time hold it until the
“Start/Stop” LED flashes rapidly (5 flashes per second).
Acknowledgement indicator:
“Start/Stop” LED flashes rapidly (5 flashes per second).
If access is not successful, the machine will automatically revert to standard
operating mode.
Options:
1. Press the Buzzer button to select a programming function.
2. The “Buzzer” LED flashes to indicate the selected function. See Table 090-4.
3. Press the Start/Stop button to select options.
4. The “Drying” LED flashes to indicate the selected option. See Table 090-4.
