Technical Information
9
T 80xx
C Technical Data
Casing
Design Generation 2000
Frame design
Condenser or vented dryer
Control panel
Program LEDs, on/off button
Dimensions
Height with/without lid 33.5”/32.3” (850mm/820mm)
Width 23.4” (595mm)
Depth 22.8” (580mm)
Power cord length
6.5' (2m)
Hose length
5' (1.5m)
Control
technology
Single-board electronic
Novotronic IV Midi pushbuttons
Condenser dryer: EPWL 314
Vented dryer: EPWL 315
T 8019CI: EPWL 316-DI
Update capable via optical PC
interface
Drying
technology
Heater bank
2-filament heater bank, 2.6kW
Temperature limiter
Temperature limiter (SOD) 347°F
(175°C) on heater bank
NTC NTCs on heater bank and at fill ring
Residual-moisture sensing Conductivity process
Insufficient-air detection
Via heater bank NTC (2R30) and fill-
ring NTC (1R30)
Drum speed 48 - 57 rpm
Table C-1: Technical Data, Novotronic IV (Single-Board Electronic)
