Technical Information
13
T 980x/T 982x
1 Technical Data
Design
Upright, frame construction, side walls
embossed for reinforcement
Table 010-1: Casing Technical Data
4 Service
4.1 Lid Removal
1. Disconnect the machine from the power supply.
2. Remove the screw caps on the sides. See Figure 010-1.
3. Loosen the T20 screws a maximum of 5 turns. Do not unscrew the
screws completely.
4. Press in on the screws.
5. Lift the lid at the front and slide it back to release it from its retainers.
Take the lid off.
Figure 010-1: Lid Removal
