Miele T 980x - Figure 010-3: Side Panel Removal

Technical Information
15
T 980x/T 982x
4. Remove the side panel retaining screws (nine T20s per panel). See
Figure 010-3.
5. Take the side panel(s) off.
Figure 010-3: Side Panel Removal
Note:
When re-installing the side panels, ensure that the screws with serrated
washers (ground screws) are installed in the correct positions.
