Miele T 980x - Installing the Gas Burner; Figure 031-13: Gas Regulation Valve

Technical Information
39
T 980x/T 982x
4.5 Installing the Gas Burner
1. Secure the burner with a screw. See Figure 031-13.
Figure 031-13: Gas Regulation Valve
2. Install the gas solenoid valve; refer to Section 031-4.3.
3. Attach the left side panel; refer to Section 010-4.3.
4. Attach the front panel; refer to Section 010-4.2.
5. Attach the fascia panel.
6. Install the dryer lid; refer to Section 010-4.1.
Warning!
Perform an electrical safety check.
Perform a gas safety check.
With the system under normal gas pressure, check the gas connections for
a tight seal using a spray such as Leak Test.
Check the dryer for correct function.
