Technical Information
36
T 980x/T 982x
Figure 031-8: Disconnecting the Gas Regulation Valve
7. Remove the retaining bracket of the gas regulation valve using a metric
7mm Allen wrench and a Phillips-head screwdriver.
8. Take the gas regulation valve off the burner.
4.3 Installing the Gas Solenoid Valve
Warning!
Clean soiled components with spray cleaner (MICROTEC Profi-Clean, mat.
no. 05321000).
1. Insert the gas regulation valve into the burner.
2. Fasten the bracket of the gas regulation valve, using a metric 7mm Allen
wrench and a Phillips screwdriver.
3. Using two metric 17mm wrenches, attach the gas connecting line to the
gas regulation valve. Fasten the connecting nut and turn all the way to its
stop. See Figure 031-9.
Figure 031-9: Attaching the Gas Connecting Line to the Gas Regulation Valve
