Technical Information
17
T 980x/T 982x
1 Technical Data
Door
Porthole door. Door hinge is on the left
and cannot be reversed.
Lock
Manual pull-open lock.
Door lock contact switch (A2). Drum
door open = contact open.
Table 020-1: Door Technical Data
2 Function
2.1 Door Lock (A2)
Pull the door open.
An open door is registered by a microswitch in the door lock
(drum door open = contact open).
4 Service
4.1 Door Removal
1. Disconnect the appliance from the power supply.
2. Take off the front panel; refer to Section 010-4.2.
3. Turn the front panel around and remove the two locknuts (Figure 020-1,
Item 1) with an 8-millimeter nut driver or wrench.
4. Carefully separate the door from the front panel.
