Technical Information
38
T 980x/T 982x
6. Attach the right side panel.
7. Attach the front panel.
8. Attach the fascia panel.
9. Attach the dryer lid.
Warning!
Perform an electrical safety check.
Perform a gas safety check.
With the system under normal gas pressure, check the gas connections for
a tight seal using a spray such as Leak Test.
Check the dryer for correct function.
4.4 Removing the Gas Burner
1. Disconnect the machine from the power and gas supplies.
2. Remove the dryer lid; refer to Section 010-4.1.
3. Remove the front panel; refer to Section 010-4.2.
4. Remove the left side panel; refer to Section 010-4.3.
5. Remove the gas solenoid valve; refer to Section 031-4.2.
6. Loosen the burner retaining screw and take the burner off. See Figure 031-12.
Figure 031-12: Gas Regulation Valve
