6.3. “C” bracket for MacroPATH camera
CODE
DESCRIPTION
Q.TY
370488V
“C” support for ceiling/wall
camera mounting
1
Secure the ceiling bracket to the camera by means of the front holes with the 2 M6x40 screws (with washers
and nuts) supplied.
Alternatively, rotate the support as shown in the picture using the top holes using the 2 M6X16mm screws
(with washer) provided.
No screws are included to secure the entire unit, as this depends on the thickness and type of wall that you
need to attach it to.
