SECTION 3 − DEFINITIONS
3-1. Additional Safety Symbols And Definitions
Warning! Watch Out! There are possible hazards as shown by the symbols.
Safe1 2012−05
Do not move or operate unit where it could tip.
Safe 113 2013−04
3-2. Miscellaneous Symbols And Definitions
A
Amperes
V
Volts
Remote
Protective Earth
(Ground)
On
Off
Alternating
Current
I
2
Rated Welding
Current
X
Duty Cycle
U
1
Primary Voltage
Line Connection
U
2
Conventional
Load Voltage
U
0
Rated No Load
Voltage (OCV)
IP
Degree Of
Protection
I
1max
Rated Maximum
Supply Current
I
1eff
Maximum
Effective Supply
Current
Hz
Hertz
Percent
Output
S
Suitable For
Areas Of
Increased Shock
Hazard
Alternating
Current (AC) And
Direct Current
(DC)
Direct Current
(DC)
Gas Tungsten Arc
Welding (GTAW)
Shielded Metal
Arc Welding
(SMAW)
Up
Rated Peak
Voltage
Inverter Power
Source With
AC/DC Output
Notes
