Miller Syncrowave 250 DX - 3-13. Front Panel Display For TIG HF Impulse DCEN

OM-363 Page 16
3-13. Front Panel Display For TIG HF Impulse DCEN (Direct Current Electrode Negative)
1 Front Panel
Correct front panel display for ba-
sic TIG HF Impulse DCEN
welding.
 For all front panel switch pad
controls: press switch pad to
turn on light and enable
function.
NOTE: Green on nameplate indi-
cates a TIG function (see Section
4-1 for description of controls).
1
1
(CE Nameplate)
