Miller Syncrowave 250 DX - 3-17. Front Panel Display For Stick DCEP

OM-363 Page 20
3-17. Front Panel Display For Stick DCEP (Direct Current Electrode Positive)
1 Front Panel
Correct front panel display for
basic Stick DCEP welding.
 For all front panel switch pad
controls: press switch pad to
turn on light and enable
function.
NOTE: Gray on nameplate indi-
cates a Stick function (see Sec-
tion 4-1 for description of con-
trols).
1
1
(CE Nameplate)
