Mahr GmbH, Millimar C1208/C1216/1240

Table of Contents

Default Chapter1
- Operating Instructions1
- Safety Instructions5
- Table of Contents7
Initial Commissioning10
1 General Points13
2 Control Elements14
3 Performing Basic Settings21
- Selecting the Display Language21
- Setting the Contrast22
- Setting the Unit of Measurement23
- Setting the Resolution/Display Format of the Measured Value24
- Selecting the Number of Features/Test Results to be Displayed25
4 Positioning the Probe in the Measuring Device (Setup)27
5 Aligning Probe Sensitivity28
- Calibrating a Measuring Channel29
- Aligning the Sensitivity of the Probe30
  - Connected to C130
6 Inputting Settings for Calculation and Display of a Feature31
- Setting the Factor for Correcting the Indicated Value of a Feature31
- Selecting a Channel or Channel Connection (Formula)33
7 Selecting a Feature34
8 Master Measurement36
- How to Select the Type of Master Measurement38
- Entering the Nominal Master Value for a One-Point Master Measurement38
- Entering the Nominal Master Value for a Two-Point Master Mea Sure Ment39
- Carrying out a One-Point Master41
- Measurement41
- Carrying out a Two-Point Master41
9 Setting Tolerances and Limit Values42
- Setting Tolerance Limits42
- Setting Warning Limits44
- Setting the Color of the Status Lamps for Warning and Tolerance Limits46
- Setting Plausibility Limits47
10 Setting Parameters for Recor Ding Measured Values48
- Setting Filter Parameters48
- Specifying the Measuring Sequence50
- Operating Mode "NORMAL52
- Operating Mode "AUTOM52
- Entering a Start Delay53
11 Password Protection54
12 Performing Measurements55
- Performing an Aggregate Measure56
  - Ment56
- Performing a Differential56
  - Measurement57
- Performing a Radial Run-Out Measure57
  - Ment57
13 Measured Value Memories58
14 Using the Serial Interface (RS 232)60
- Selecting the Interface Protocol60
- Selecting the Data Transfer Format62
- Selecting the Handshake63
- Selecting the Transfer Rate64
- Selecting How to Initiate Data Transfer65
- Examples of Interface Configuration66
- Connecting to a PC Using a Zero- Modem Cable (Circuit Diagram )71
15 Using the Parallel (I/O) Interface72
- Digital Control Output73
- Digital Control Input74
- Application Examples for the Use of Digital Control Inputs and Outputs76
- Analog Output77
  - (C 1216/C 1240 Only !!)77
  - Selecting the Feature to be77
    - Indicated77
    - The Analog Output79
16 Restoring the Factory Settings80
17 Error Messages81
18 Technical Data82
19 Mahr Contacts84
20 Warranty84
21 Index85
Navigating the Catalog of Functions and Parameters91
