Adjustments 7-5
NOTE:
After changing the 13.3 inch LCD screen, parameter setting must be performed
before using.
7.2 Control Panel Adjustment
 Control Panel Position Adjustment
Press the control lever downwards for about 30° to rotate the control panel ±45°. Press the lever
downwards for about 60° to move the control panel upwards or downwards.
 Key backlit brightness adjustment
In the [System Preset]→[Key Config] page, you can adjust key backlit brightness and volume.
 Functional keys setting
In the [System Preset]→[Key Config] page, you can preset functions for keys of <Print>,
<Save>, <P>, <F3>, <F4>, <F5>, <F6>, <F12>, for example, you can preset save image to
hard drive function of F3.
Control
lever

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
