Mindray DC-70 Exp User Manual

Field Replaceable Unit
8-1
8 Field Replaceable Unit
This chapter lists the details of the Field Replaceable Units (FRU) of the system. Please refer to the exploded view and the FRU table below.
Level 0 represents the main assemblies of the system, and the whole system is divided into 7 assemblies.
Level X represents the main parts of Level 0 assembly.
Level X-1 represents the sub-parts of Level X.
If order number is provided in the table, it means the part is an FRU and can be ordered; if the order number is not provided in the table, it
means the part is not an FRU and cannot be ordered.

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
