Field Replaceable Unit 8-25

8.2.7 Base Power Box Assembly (G0)

No.

Order Number

Part Name

Qty.

Remark

G1 115-075421-00 Power-in Assembly(2161/FRU) 1 /

G2 115-059039-00 AC Connecting Board(2143/FRU) 1 /
