Mindray DC-70 Exp User Manual

System Installation 3-19
NOTE: Please do not switch [Disable Wifi]/[Enable Wifi] frequently. If [Start]/[Stop] button become
available after frequent switching or the DC-70 can no longer search any other hotspots,
please click [Disable Wifi] again and then click [Enable Wifi] to see if it works.
3.5.6 Network Configuration
 TCP/IP setting
Click the network icon in the bottom-right corner of the screen (including wireless connection icon
and wired connection icon ) to enter TCP/IP setting:
a) Click [IP Config] to open the page:
b) Select “DHCP”, and then click [OK].

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
