Troubleshooting of Regular Malfunctions
13-1
13 Troubleshooting of Regular
Malfunctions
13.1 System Cannot Power On
13.1.1 Related Modules or Boards
No. Descriptions Remarks
1 DC-DC board /
4 AC-DC board /
5 Mother board assembly /
6 PC carrier board /
7 PC module assembly /
8 AC connection board /
13.1.2 Key Points Supporting Troubleshooting
No. Key Points Supporting Troubleshooting Remarks
1 Power-on status indicator
Backlight of the power
button
2 AC indicator
On the control panel
3 Three power supply indicators On IO back board. Define as 3.3
V/5 V/12 V

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
