Field Replaceable Unit 8-5
8.2.2 Monitor Support Arm Assembly (B0)
No. Order Number Part Name Qty. Remark
B1 115-048345-00 Monitor Support Arm Assembly(FRU) 1
B2 043-008277-00 Proactive Cover of Monitor's Support Arm 1
B3 043-008884-00 Arm Cover 1
B4 115-051552-00 Display Base Assembly(FRU) 1
B1
B2
B4
B3
