8-8 Field Replaceable Unit
No. Order Number Part Name Qty. Remark
C1 043-003505-
00
Behind panel cover 1
C2 043-003504-
01
Bevel panel cover 1
C3
115-051489-00
Touch Screen Assembly(13.3"/FRU)
1
C4 020-000049-00 SPEAKER 8ohm 4.5W wire 1 Including one loudspeaker
C5 043-008974-
00
Top cover of right speaker 1
C6 043-008973-
00
Top cover of left speaker 1
C7 044-000610-00 Bevel control base 1
C8 115-024688-00 Left Probe Holder Assembly Kit 1 For upgrade use and repair
C9 115-024689-00 Right Probe Holder Assembly Kit 1 For upgrade use and repair
C10
115-024667-01
Gel Warmer Module Kit
1
For upgrade use and repair
C11 043-009107-
00
4D Probe Holder 1
C12 043-009105-
00
Big Probe Holder 1
C13 043-009106-
00
Small Probe Holder 1
C14 043-003501-00 Spring arm of transducer holder 1
C15 043-002302-00 probe cable hook 1
C16 044-000412-00 main control base 1
C17 043-009694-00 Decoration cover of control panel(2145) 1
C18 115-052371-01 Small Keyboard Assembly(2145/FRU) 1
C19 043-003499-00 Top cover of control handle 1
C20 044-000413-00 Control handle 1
C21 031-000869-00 Ball bearing runner.SKY27 2 Order Number includes only one Slide rail
