Field Replaceable Unit 8-11
No. Order Number Part Name Qty. Remark
C23 043-004910-00
TGC Cap 1
C24 115-051517-03
Keyboard Assembly(2145/FRU) 1 Need to upgrade the software to V4.2.1
C25
801-2119-00034-00
TGC Silica(FRU)
1
C26 115-057729-00 TGC Board(2148/FRU) 1
C27 115-041020-00
Encoder Board(2123&2127 FRU) 1
C28 023-001157-00
2" trackball 1
C28-10
C28-11
