Mindray DC-70 Exp User Manual

8-16 Field Replaceable Unit
No. Order Number Part Name Qty. Remark
E1 043-009176-00 fixing loop(2143) 1
E2 044-000742-00 host handle 1
E3
115-050641-00
Top cover assembly(2143)
1
E4 115-050644-00 Back cover assembly(2143) 1
E5 115-025799-00 Right Cover Assembly(FRU) 1
E6 115-041686-00 Left Cover Assembly(2123,CE&FDA,FRU) 1
E7 115-052373-00 Front-in Assembly(2145/FRU) 1
E8 043-009175-00 printer Cover(2143) 1
E9 115-052366-00 Front cover assembly(2145/FRU) 1

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
