Mindray DC-70 Exp User Manual

Field Replaceable Unit 8-19
No. Order Number Part Name Qty. Remark
E12-1 115-051521-00 IO Board Assembly(FRU) 1
E12-2
115-051210-00 WIFI Module Kit(EWM-W163M201E) 1
Including Wi-Fi card and the Wi-Fi antenna.
For upgrade use
023-001528-00 Wi-Fi module Wi-Fi + BT 1 Only Wi-Fi card. For repair.
E12-3 024-000965-00 M.2 port wifi antenna 1 Including one Wi-Fi antenna
E12-3
E12-2
E12-1

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
