Mindray DC-70 Exp User Manual

Field Replaceable Unit 8-27
No. Order Number Part Name Qty. Remark
H9 009-003625-01 MAIN CABLE ASSEMBLY 1
Including signal cable and power cable to main
display, signal cable and power cable to control
panel, connecting cable to left and right
loudspeaker.
H10 009-009184-00 touch panel cable assembly 1
Including display signal cable, power cable, and
USB signal cable to touch screen
H11 009-003644-00 signal cable to ECG 1 System mother board,J33 - ECG module assembly
H12 009-003636-00 battery wires 1 System mother boardJ36-battery Assembly
H13 009-003646-01 PEN PROBE cable 1 System mother board,J51 – pencil probe port
H14
009-003637-01
SATA cable for DVD
1
System mother board,J48 – DVD assembly
H15 009-003624-00 PRINTER POWER CABLE 1 AC connecting board,J4 - printer chamber
H16 009-003638-00 SATA cable for HDD 1 System mother board,J35 - HDD
H17 009-003906-00 power cable for HDD 1 System mother board,J34 - HDD
H18 009-003623-00 DC POWER CONTROL CABLE 1 System mother board,J37 – switch control board
H19 009-003556-00 DC OUTPUT 12V WIRES 1
AC-DC board J4&J6 -System mother
board,J54&J55
H20 009-003557-00 DC GND WIRES 1
AC-DC board J3&J5 -System mother
board,J56&J57
H21 009-008628-00 AC-DC POWER BOARD 24v OUTPUT WIRE 1
AC-DC Module,CN1&CN2 - 24V to 12V Power
Conversion board,J1&J2
H22 009-009056-00 battery interval board contact wire 1
24V to 12V Power Conversion board,J10/J11
-Battery connecting board,J1
H23 009-009057-00 battery wires 1
System mother board,J36 - 24V to 12V Power
Conversion board,J8

Mindray DC-70 Exp Specifications

General

Touch Screen Size	10.4 inch
Probe Ports	4
Power Supply	100-240V AC, 50/60Hz
Connectivity	DICOM, USB, Ethernet
Applications	Abdominal, Cardiac, OB/GYN, Vascular
Weight	85 kg
Doppler Modes	PW, CW, Color Doppler, Power Doppler
Imaging Modes	2D, M-Mode, 4D
Storage	500GB hard drive
