C-2 Description of Self Test Items
Z0902 Primary LCD Monitor Serial Number Test
Z0903 Primary LCD Monitor Configuration Test
Z0904 Primary LCD Monitor Brightness Control Test
Z0905 Primary LCD Monitor Backlight Control Test
Secondary LCD Monitor I2C Interconnection Test
Z1002 Secondary LCD Monitor Brightness Control Test
Z1101 Touch Screen USB Communication Test
Z1102 Touch Screen Function Test
Z1201 Mini CW Board ID Test
Z1301 DSP FPGA and 4D&TEE Board Interconnection Test
Z1302 4D&TEE Board Driver Circuit Test
4D&TEE Board Programmable Voltage Test
Z1304 TEE Temperature Signal Test
Z1305 TEE Angel Signal Test
Z1401 DSP FPGA and ECG Board Interconnection Test
Z1402 ECG Board Self Test
Z1501 MF FPGA and SM ARM Interconnection Test
Z1502 Left Battery I2C Interconnection Test
Z1504 Battery I2C Interconnection Test
Z1505 Battery Test
Description of Self Test Items (Old
PC Box Assembly before EAF518F)
PC Module and MF FPGA Interconnection Test
Z0202 CPU and GPU Temperature Pressure Test
Z0203 MF FPGA and System Monitor Interconnection Test
Z0204 Back End Voltage Monitor Test
Z0205 System Temperature Test
Z0206 Fan Speed Test
Z0207 Speaker Test
Microphone Interface Test
Z0209 Network Interface Test
Z0210 WIFI Function Test
Z0301 Front End Voltage Monitor Test
Z0401 DSP FPGA and TRA Interconnection Test (Control Interface)
Z0402 TRA AFE SPI Interface Test
Z0403 TRA AFE Test Mode
