Mindray DC-80A Service Manual

Field Replaceable Unit 8-35
No.
Order Number
Part Name
Qty.
Remark
G5
115-059038-00
AC-DC Module(2143/FRU)
1
/
G6
043-003480-00
base filter
3
Including one dust-proof filter.
G7
115-058955-00
Li-ion battery
2
Including two pcs batteries. For CE.
115-065137-00
Li-ion battery
2
Including two pcs batteries. For FDA.
8.2.8 Cable (H0)
No.
Order Number
Part Name
Qty.
Remark
H1
009-009186-00
USB cable for keyboard
1
Control panel,J4 - Small keyboard
H2
009-003647-00
HEATER PWR CABLE
1
Control panel,J6 - Gel warmer port
H3
2105-20-40478
Grounding Cable of control board
1
Control panel - grounded to shield
H4
2108-20-65853
STC connecting cable
1
Control panel,J7 – TGC board,J1
H5
009-003635-00
encoder signal wire
1
Control panel,J2 – Encoder board,J1
H6
009-004599-00
Trackball connecting cable
1
Control panel,J8 - Trackball
H7
009-009185-00
cable for USB CONN
1
Control panel,J12/13 - USB port
H8
009-002560-00
USB CABLE
1
Control panel,J10 - System mother board,J45
