Mindray DC-80A Service Manual

3-14 System Installation
3.4.4 Position a Printer
Open the video printer compartment gate and position the printer inside.
3.4.5 Installing Barcode Scanner
The system supports barcode reader to read the patient information (ID).
1. For structure of the scanner, see the figure below. The important parts are: LED indicator,
scanning surface, and the switch.
2. Connect the cable to the port on the scanner.
3. Connect the other end of the cable to the USB port on the ultrasound system.
Switch
Scanning surface
LED indicator
Gate
