Mindray DC-80A Service Manual

System Installation 3-13
In "[Setup]→ [Print Preset]" screen, select the "Report Print" column in the service list. You can
select printer from the driver list next to “Printer” in the lower screen and set the items in the
"Property" box. Click [Save] after you have finished setting.
Please refer to the accompanying manuals of the printers for more details.
3.4.3 Installing Video Printer
The system support both black/white video printers (digital) and color video printers (digital).
CAUTION：
The auxiliary power outlet in the system is used to supply power for
approved peripheral devices. Do not connect other/unapproved
devices to this outlet; otherwise the rated output power may be
exceeded and the system failure may result. Maximum output power
of the outlet is 240VA.
◼ Local printer installation
1. Position the printer in the proper place.
2. Plug the printer power cord into an appropriate outlet.
3. Use a USB cable to connect between the system's USB port and the printer's USB port.
4. Load a paper roll, and turn on the system and printer.
See section “3.4.2 Installing a Graph / Laser Printer” for the driver installation procedure.
Note: Unless otherwise specified, printer drivers listed in chapter “2.1.3 Peripherals Supported” are
installed already.
5. Add a print service:
(1) Open the “[Setup] → [Print Preset]” screen.
(2) Click [Add Service] to enter the page.
(3) Select the service type and enter the service name manually.
(4) Click [OK] to return to the page.
(5) Select the target printer from the drop-down list in the “Property” box and set other printing
properties.
(6) Click [Save] to complete.
