Mindray DC-80A Service Manual

Field Replaceable Unit 8-37
No.
Order Number
Part Name
Qty.
Remark
H16
009-003637-01
SATA cable for DVD
1
System mother board,J48 – DVD assembly
H17
009-003624-00
PRINTER POWER CABLE
1
AC connecting board,J4 - printer chamber
H18
009-003638-00
SATA cable for HDD
1
System mother board,J35 - HDD
H19
009-003906-00
power cable for HDD
1
System mother board,J34 - HDD
H20
009-003623-00
DC POWER CONTROL CABLE
1
System mother board,J37 - 24V to 12V Power
Conversion board,J12
H21
009-003556-00
DC OUTPUT 12V WIRES
1
24V to 12V Power Conversion board,J4&J6
-System mother board,J54&J55
H22
009-003557-00
DC GND WIRES
1
24V to 12V Power Conversion board,J3&J5
-System mother board,J56&J57
H23
009-009057-00
battery wires
1
System mother board,J36 - 24V to 12V Power
Conversion board,J8
H24
009-008625-00
AC-DC power board input wire
1
AC connecting board,J2 - AC-DC Module,CN3
H25
009-008628-00
AC-DC POWER BOARD 24v OUTPUT
WIRE
1
AC-DC Module,CN1&CN2 - 24V to 12V Power
Conversion board,J1&J2
H26
009-004582-00
auxiliary output control signal cable
1
24V to 12V Power Conversion board,J7 - AC
connecting board,J1
H27
009-009056-00
battery interval board contact wire
1
24V to 12V Power Conversion board,J10/J11
-Battery connecting board,J1
