12-16 DICOM
12.2 Verify Connectivity
If you want to verify connectivity (it is not a must), you can click [Verify] button on the
pages of DICOM Service screen respectively.
If the verification succeeds, it will prompt “xxx Verify Succeed”.
Otherwise, it prompts “xxx Verify Failed”.
If verification failed, the possible causes may be:
The ultrasound machine can’t communicate normally with the server. Please
check if the cable is properly connected; or,
Check if the IP of the server is configured in the same segment with that of the
ultrasound machine; or,
Check if the network adapter, the router, the exchanger and the HUB are normally
working.
The server does not support the verification. If the connection is normal, it can be
concluded that the server does not support the verification.
The server supports the verification, but this function is not activated. Please
check if the verification function is activated.
Tips:
Not all the SCPs can support verification; please consult SCP belongings to confirm
whether SCP can support this service. If not, the verification won’t pass.
12.3 DICOM Service
If the system is configured with DICOM modules, and connected to the relevant DICOM
servers, after verifying connection, you can perform storage, print, Worklist, storage
commitment, structured report and query/ retrieve applications.
12.3.1 DICOM Storage
DICOM Storage is used to send image(s) to DICOM storage server for storage.
Send image in iStation/Review/main screens:
(1) Select image(s)
Press <iStation> to enter the iStation screen, click to select an exam record in the
list, where thumbnails are displayed in the thumbnail area in the lower part of the
screen, and then click to select a thumbnail or several thumbnails. Or,
Press <Review> to enter the Review screen, click to select an image or several
images. Or,
On the main screen, select a thumbnail or several thumbnails.
(2) On the iStation/Review screen, click the corresponding [Send To] button, or, on
the main screen, click at the right side of Thumbnail area. The following
dialogue box pops up:
