Setup 15-17
Available tools are described as follows:
b) Check on the screen, move the cursor onto the probe mark and
press <Set>, adjust the position with the trackball and direction with the
multifunctional knob.
c) After the drawing of a body mark is completed, click [OK] to save it and exit
the user-defined body mark status.
 Edit/ delete a user-defined body mark
After selecting a user-defined body mark, click the [Edit] button to edit it.
 Delete
After selecting a user-defined body mark, click [Delete] to delete the selected image.
 Load:
Click [Load] to load user-defined body mark from external media.
 Export
Click [Export] to export user-defined body mark to external media.
Left/right flip Up/down flip
Brush Eraser
Zoom in
Zoom out
Rotate
Drag
