System Preparation 3-11
Acoustic power & MI/TI
Display the acoustic power, including the acoustic power, MI (Mechanical Index)
and TI (Thermal Index).
Freeze icon
The freeze icon means the image is frozen.
Patient Information
Displays patient name, ID, gender and age etc. Enter the patient information
through the "Patient Info" screen. Or, import the saved patient data from iStation
or the DICOM Worklist server.
Probe Model
Display the currently-used probe model, or the default model.
Exam Mode
Displays the currently used exam type, e.g. A-Abdomen, is displayed.
Operator
Displays the operator’s name on the screen. This information is entered through
the “Patient Info” screen.
ECG icon
Displays ECG icon, which consists of a heart icon and heart rate, e.g. " 75bpm"
Accession#
Serial number used in DICOM or the manually entered serial number in “Patient
Info” screen.
Image Parameter and Menu Area
The image parameter and menu are both displayed in this area. When no menu is
available; this area displays the image parameters of the current mode.
Menu area
When an image menu is displayed, the imaging parameters will be covered by
the menu.
Include image menu, measurement menu, comment menu, body mark menu and
so on. Use the trackball or the multifunctional knob to operate on the menu.
Use the <Menu> to show or hide the menu, or press the multifunctional knob.
The menu area consists of menu title, menu items and page-turning button. As
shown in figure below.
